Specifications
Manufacturer: TSC Auto ID Technology Co., Ltd
Manufacturer Part Number: 99-135A001-0011
Manufacturer Website Address: http://www.tscprinters.com
Brand Name: TSC Printers
Product Series: TTP-286MT
Product Model: TTP-384MT
Product Name: Industrial Thermal Transfer Bar Code Printer
Product Type: Direct Thermal/Thermal Transfer Printer
Technical Information
Recommended Use: Receipt Print
Print Color Capability: Monochrome
Maximum Mono Print Speed: 4 in/s
Maximum Print Resolution (dpi): 300
Maximum Print Length: 16.67 ft
Maximum Print Width: 8.64"
Barcode Symbology Supported:
Connectivity Technology: Wired
Real Time Clock: Yes
Application/Usage:
Features: LCD Display
Memory
Standard Memory: 256 MB
Interfaces/Ports
Parallel Port: Yes
USB Host: Yes
Serial Port: Yes
USB: Yes
Network & Communication
Ethernet: Yes
Ethernet Technology: Ethernet
Display & Graphics
Display Screen: Yes
Screen Size: 4.3"
Display Screen Type: LCD
Touchscreen: Yes
Media Types & Handling
Media Type:
Media Sensor:
Media Thickness: 10 mil
Maximum Roll Diameter: 8.20"
Maximum Label Width: 9.50"
Maximum Label Length: 16.67 ft
Fonts & Emulation
Language Emulation:
Reliability
Print Head Life: 50km
Power Description
Power Source: AC Supply
Environmental Conditions
Operating Temperature: 41°F (5°C) - 104°F (40°C)
Operating Relative Humidity: 20% - 85%
Storage Temperature: 14°F (-10°C) - 140°F (60°C)
Storage Relative Humidity: 10% - 90%
Physical Characteristics
Height: 13.2"
Width: 17.3"
Depth: 20.2"
Weight (Approximate): 52.25 lb
Miscellaneous
Optional Connectivity:
Platform Supported: PC
Certifications & Standards: FCC Class A, CE Class A, UL, CUL, T‹V/Safety
Environmentally Friendly: Yes
Manufacturer: TSC Auto ID Technology Co., Ltd
Manufacturer Part Number: 99-135A001-0011
Manufacturer Website Address: http://www.tscprinters.com
Brand Name: TSC Printers
Product Series: TTP-286MT
Product Model: TTP-384MT
Product Name: Industrial Thermal Transfer Bar Code Printer
Product Type: Direct Thermal/Thermal Transfer Printer
Technical Information
Recommended Use: Receipt Print
Print Color Capability: Monochrome
Maximum Mono Print Speed: 4 in/s
Maximum Print Resolution (dpi): 300
Maximum Print Length: 16.67 ft
Maximum Print Width: 8.64"
Barcode Symbology Supported:
- Code 39
- Code 93
- Code 128 UCC
- Code 128 (A/B/C)
- Codabar
- Interleaved 2 of 5
- EAN-8
- EAN-13
- UPC-A/E
- UPC-5 Digits Add-on
- UPC -2 Digits Add-on
- MSI
- Plessey
- POSTNET
- RSS Stacked
- GS1 DataBar
- PDF-417
- Code 11
- Maxi Code
- Data Matrix
- QR Code
- AZTEC
Connectivity Technology: Wired
Real Time Clock: Yes
Application/Usage:
- Industrial
- Desktop
Features: LCD Display
Memory
Standard Memory: 256 MB
Interfaces/Ports
Parallel Port: Yes
USB Host: Yes
Serial Port: Yes
USB: Yes
Network & Communication
Ethernet: Yes
Ethernet Technology: Ethernet
Display & Graphics
Display Screen: Yes
Screen Size: 4.3"
Display Screen Type: LCD
Touchscreen: Yes
Media Types & Handling
Media Type:
- Label
- Continuous Label
- Die-cut Label
- Fanfold
- Tag
- Notched
- Black Mark
Media Sensor:
- Multi-position Transmissive/Gap Sensor
- Moveable Reflective/Black Mark Sensor
- Head Open Sensor
Media Thickness: 10 mil
Maximum Roll Diameter: 8.20"
Maximum Label Width: 9.50"
Maximum Label Length: 16.67 ft
Fonts & Emulation
Language Emulation:
- TSPL-EZ
- EPL
- ZPL
- ZPL II
Reliability
Print Head Life: 50km
Power Description
Power Source: AC Supply
Environmental Conditions
Operating Temperature: 41°F (5°C) - 104°F (40°C)
Operating Relative Humidity: 20% - 85%
Storage Temperature: 14°F (-10°C) - 140°F (60°C)
Storage Relative Humidity: 10% - 90%
Physical Characteristics
Height: 13.2"
Width: 17.3"
Depth: 20.2"
Weight (Approximate): 52.25 lb
Miscellaneous
Optional Connectivity:
- Bluetooth
- Wireless LAN
Platform Supported: PC
Certifications & Standards: FCC Class A, CE Class A, UL, CUL, T‹V/Safety
Environmentally Friendly: Yes
- SKU:
- 1060361385
