The B126-1A0 is a receiver unit that is used with the B126-002 and B126-004 transmitter units. It extends a 1080p (60Hz) signal to a monitor up to 150 ft. away using Cat5e/6 cable. To achieve maximum distance and resolution, use 24Awg Solid Wire Cat5e/6 cable. (Tripp Lite's N202-Series) It features a built-in Equalization control for adjustment of the video image. Supports 24-bit True Color (8-bits per channel), HDCP, 3D, and both stereo audio and 7.1 channel surround sound audio (7.1 channel surround sound signal will be Multi-Channel or PCM). Installation is simple. Connect the transmitter unit to an HDMI source using a Tripp Lite P568-Series HDMI cable (not included). Connect the receiver unit to a display using a Tripp Lite P568-Series HDMI cable (not included). Finally, connect the receiver to the RJ45 port on the transmitter using a single Cat5e/6 cable. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
-
SKU:
- 1017538546
Manufacturer:
Tripp Lite by Eaton
Manufacturer Part Number:
B126-1A0
Manufacturer Website Address:
http://www.tripplite.com
Brand Name:
Tripp Lite
Product Model:
B126-1A0
Product Name:
B126-1A0 Video Console
Product Type:
Video Extender Receiver
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Number of Output Devices Supported:
1
Maximum Operating Distance:
200 ft
Network (RJ-45):
Yes
HDMI Out:
Yes
Number of Network (RJ-45) Ports:
1
Number of HDMI Outputs:
1
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 6
Product Color:
Black
Receiver Height:
1"
Receiver Width:
2.50"
Receiver Depth:
3.60"
Form Factor:
Wall Mountable
Package Contents:
- B126-1A0 Video Console
- Screwdriver for Adjustment of Equalization
- Mounting Hardware
- External Power Supply
- Owner's manual
Environmental Certification:
RoHS
Country of Origin:
Taiwan
TAA Compliant:
Yes
Limited Warranty:
1 Year
sku variation:
The Tripp Lite B126-1A0 is also known as TRI-B1261A0 or B1261A0
Brand Logo:
https://content.etilize.com/Brand-Logo/1017538546.jpg
Short Description:
Tripp Lite, Hdmi Over CAT5 Active Extender Remote Unit 1080P 60HZ TAA GSA
Manufacturer-Brochure:
https://content.etilize.com/Manufacturer-Brochure/1017538546.pdf
Accessories:
11200812,1017538547,1017538547,1017538548,1017538548,11200812
