Universal Barcode Scanning Sled
The DuraSled™ DS840 is a universal barcode scanning sled for 1D/2D barcodes, with Bluetooth® wireless technology for Apple iPhones and iPods. The DuraSled reads printed or on-screen barcodes. It is easy-to-use and ideal for delivery services, asset tracking, ticketing, and other application-driven mobile solutions. Its rugged case protects phones from drop damage and provides a robust, versatile charging solution suitable for all workplace environments. Simply insert your iPhone/iPod, pair your scanner and you are ready to go.
DuraSled supports iPhone 6, 7, 8, iPhone X series, SE 2022, and the entire iPhone 11 and 12 series. This makes it easy for workers to mix and match DuraSled™ solutions for iPhones, all while using the same accessories and application. The core components don't change when switching to a new iPhone model, enabling users to maintain their mobile deployment investments for a relevant number of years.
The Capture SDK enables easy integration into native, and/or web-based applications that use scanning to enhance the productivity of workers using iPhones.
-
SKU:
- 1076422469
Manufacturer:
Socket Mobile, Inc
Manufacturer Part Number:
CX4088-3155
Manufacturer Website Address:
http://www.socketmobile.com
Brand Name:
Socket Mobile
Product Line:
DuraSled
Product Model:
DS840
Product Name:
DS840 Barcode Sled Scanner
Packaged Quantity:
6 Unit
Product Type:
Barcode Scanner
Connectivity Technology:
Wireless
Scanning Capability:
1D,2D
Barcode Symbology Supported:
1D:
- Bookland EAN
- Chinese 2 of 5
- Codabar
- Code 11
- Code 39
- Code 93
- Code 128
- Composite CC-A/B
- Composite CC-C
- Composite TLC-39
- Discrete
Light Source:
LED
Image Sensor Type:
Imager
Scan Pattern:
Omni-directional
Scanning Distance:
19.49"
Field of View (Horizontal):
42°
Field of View (Vertical):
28°
Maximum Ambient Light:
100000 lux
Drop Specification:
Multiple drops to vinyl covered concrete at about 3 ft or 1 m
Minimum Print Contrast:
25%
Maximum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (DataMatrix):
20 mil
Minimum Element Resolution (PDF417):
6.6 mil
Maximum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
640 x 400
Bluetooth:
Yes
Host Interface:
USB
Battery Chemistry:
Lithium Polymer (Li-Polymer)
Battery Capacity:
700 mAh
Maximum Battery Recharge Time:
8 Hour
Operating Temperature:
32°F (0°C) to 122°F (50°C)
Storage Temperature:
-22°F (-30°C) to 158°F (70°C)
Humidity (Non-condensing):
5% to 95%
Form Factor:
Mobile
Rugged:
Yes
Package Contents:
- 6 x DS840 Barcode Sled Scanner
- 6 Bay Charger
- Power Cord
- 1 year limited Warranty on DuraSled and 6 Bay Charger
Ingress Protection (IP) Rating:
IP40
Application/Usage:
Retail,Logistics,Healthcare,Warehouse,Hospitality,Inventory,Field Sales/Service,Transportation
Platform Supported:
iOS
Environmentally Friendly:
Yes
Environmental Certification:
RoHS,WEEE
Limited Warranty:
1 Year
sku variation:
The Socket Mobile CX4088-3155 is also known as SOC-CX40883155 or CX40883155
Brand Logo:
https://content.etilize.com/Brand-Logo/1076422469.jpg
Short Description:
Socket Mobile, Durasled DS840, Universal Barcode Sled Reader For Iphone 12/13/14 & Iphone 12/13/14 PRO (6 Units) & 6 BAY Charger Bundle - NA & Japan
