This HDMI® over dual CAT5 extender transmits your HDMI A/V signal with IR to a remote location up to 30 m (100 ft.) away over dual CAT5/CAT6 cables.
Simplify Your Setup with No Power Adapters Required
Unlike most 1080p HDMI extenders that can require up to two power adapters, this HDMI over CAT5 extender is powered using the HDMI bus and does not require external power. Power-free installation makes your digital-signage solution simple. Mounting hardware is built into both the transmitter and receiver to ensure a discreet, professional installation.
Control Your Video Source from the Remote Display
With IR extension built-in this HDMI transmitter and receiver kit offers remote infrared extension, enabling you to control your video source from the remote display, ensuring you can always see what you're doing, even from a distance.
Crystal-clear 1080p Video
This HDMI extender maintains your 1080p picture quality, ensuring your remote picture is crystal clear. The extender also supports 7.1 audio for optimum sound quality. Support for HD video and 7.1 channel audio lets you create brilliant digital signage solutions that capture the attention of your audience.
The ST121SHD30 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
More from the Manufacturer
-
SKU:
- 1025654360
Manufacturer:
StarTech.com
Manufacturer Part Number:
ST121SHD30
Manufacturer Website Address:
http://www.startech.com
Brand Name:
StarTech.com
Product Name:
HDMI Over Cat5 / Cat6 Extender with IR - 100 ft (30m) Power Free
Product Type:
Video Extender Transmitter/Receiver
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Number of Output Devices Supported:
1
Maximum Operating Distance:
328.08 ft
Graphics Modes:
Full HD
Maximum Video Resolution:
1920 x 1080
Network (RJ-45):
Yes
HDMI In:
Yes
HDMI Out:
Yes
Number of Network (RJ-45) Ports:
4
Number of HDMI Inputs:
1
Number of HDMI Outputs:
1
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 6
Product Color:
Black
Transmitter Height:
0.90"
Transmitter Width:
1.80"
Transmitter Depth:
3.20"
Receiver Height:
0.90"
Receiver Width:
1.80"
Receiver Depth:
3.20"
Form Factor:
Rack-mountable,Desktop
Transmitter Weight (Approximate):
8.50 oz
Receiver Weight (Approximate):
8.50 oz
Package Contents:
- HDMI over CAT5e/6 UTP Transmitter
- HDMI over CAT5e/6 UTP Receiver
- 4 x Foot Pad Set
- 1 x IR Extender Kit
- 1 x Mounting brackets
- 1 x User Manual
Environmentally Friendly:
Yes
Environmental Certification:
RoHS,WEEE,REACH
Country of Origin:
China
Limited Warranty:
2 Year
sku variation:
The StarTech.com ST121SHD30 is also known as STA-ST121SHD30 or ST121SHD30
Brand Logo:
https://content.etilize.com/Brand-Logo/1025654360.jpg
Short Description:
Startech, Discontinued, No Replacement, Hdmi Over CAT5 / CAT6 Extender With Infrared IR 100FT (30M) Hdmi Video/audio Over Dual Ethernet Cable Extender Power Free 1080P
Additional-pdf1:
https://content.etilize.com/Additional-pdf1/1025654360.pdf
Additional-pdf2:
https://content.etilize.com/Additional-pdf2/1025654360.pdf
