The ST124UTPEA VGA Video Extender over Cat 5 with Audio simplifies the implementation of digital signage solutions by allowing a single VGA source and corresponding audio to be broadcast to multiple displays at up to 300m (950ft) away over standard Cat 5 or better UTP cabling.
Consisting of the transmitter unit only, this product requires a single receiver unit per remote display that you are connecting. The VGA extender offers the option of using our STUTPRXWLA wall-plate receiver.
For even more versatility, you also have the option to expand the amount of remote displays in your setup by adding the STUTPEA4X VGA & Audio over Cat 5 Line Splitter to your setup multiplying the number of potential displays by four - allowing your VGA and accompanying audio signal to be broadcast to up to a total 16 displays.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
More from the Manufacturer
-
SKU:
- 1012024121
Manufacturer:
StarTech.com
Manufacturer Part Number:
ST124UTPEA
Manufacturer Website Address:
http://www.startech.com
Brand Name:
StarTech.com
Product Name:
VGA Video and Audio over Cat5 UTP Video Extender
Product Type:
Video Extender Transmitter
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Number of Output Devices Supported:
5
Maximum Operating Distance:
984.25 ft
Graphics Modes:
WUXGA,XGA,SXGA,UXGA
Maximum Video Resolution:
1920 x 1200
Network (RJ-45):
Yes
VGA In:
Yes
VGA Out:
Yes
Number of Network (RJ-45) Ports:
4
Number of VGA Inputs:
1
Number of VGA Outputs:
1
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 5
Product Color:
Black
Transmitter Height:
1.61"
Transmitter Width:
4.70"
Transmitter Depth:
8.70"
Transmitter Weight (Approximate):
1.46 lb
Package Contents:
- VGA Video and Audio over Cat5 UTP Video Extender
- 2 x Mounting Brackets
- 3.5 MM Audio Cable M/M (3 ft)
- VGA Cable M/M (3 ft)
- 1 x 1 Bag (Screws)
- 1 x Universal Power Adapter (NA/UK/EU)
- 1 x Ins
Environmentally Friendly:
Yes
Environmental Certification:
RoHS,WEEE,REACH
Limited Warranty:
2 Year
sku variation:
The StarTech.com ST124UTPEA is also known as STA-ST124UTPEA or ST124UTPEA
Brand Logo:
https://content.etilize.com/Brand-Logo/1012024121.jpg
Short Description:
Startech, VGA Video AND Audio Over CAT5 UTP Video Extender - 4 Ports - Video/audio Extender - 4 Ports - External - UP To 300 M
Additional-pdf1:
https://content.etilize.com/Additional-pdf1/1012024121.pdf
Additional-pdf2:
https://content.etilize.com/Additional-pdf2/1012024121.pdf
Accessories:
1012024113
