The STUTPEALR VGA Video Extender over Cat 5 Remote Receiver with Audio is the receiver unit utilized by our STUTPEA VGA and Audio over Cat 5 extension series. This convenient video distribution system simplifies the implementation of digital signage solutions by allowing a single VGA source and corresponding audio to be broadcast to multiple displays at up to 300m (950ft) away.
Comprised of one receiver unit per display, and either a ST128UTPEA 8 port VGA & Audio extender unit, the VGA and Audio extension series can transmit a single VGA output and corresponding audio to four or eight displays/receivers over standard Cat 5 or better UTP cable.
For even more versatility, you also have the option to mulitply the amount of remote displays in your setup by adding the STUTPEA4X VGA & Audio over Cat 5 Line Splitter to your setup allowing your VGA and accompanying audio signal to be broadcast to up to a total 16 displays.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
-
SKU:
- 1012024113
Manufacturer:
StarTech.com
Manufacturer Part Number:
STUTPEALR
Manufacturer Website Address:
http://www.startech.com
Brand Name:
StarTech.com
Product Name:
VGA Video Extender over Cat 5 Remote Receiver with Audio
Product Type:
Video Extender Receiver
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Number of Output Devices Supported:
1
Maximum Operating Distance:
984.25 ft
Graphics Modes:
SXGA
Maximum Video Resolution:
1280 x 1024
Network (RJ-45):
Yes
Number of Network (RJ-45) Ports:
1
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 5
Receiver Height:
0.98"
Receiver Width:
4.37"
Receiver Depth:
5.12"
Receiver Weight (Approximate):
10.34 oz
Package Contents:
- VGA Video Extender over Cat 5 Remote Receiver with Audio
- 1 x Power Adapter
- 1 x Instruction Manual
Environmentally Friendly:
Yes
Environmental Certification:
RoHS,REACH,WEEE
Country of Origin:
Taiwan
TAA Compliant:
Yes
Limited Warranty:
2 Year
sku variation:
The StarTech.com STUTPEALR is also known as STA-STUTPEALR or STUTPEALR
Brand Logo:
https://content.etilize.com/Brand-Logo/1012024113.jpg
Short Description:
Startech, VGA Video Extender Over CAT 5 Remote Receiver With Audio - Video/audio Extender - External - UP To 300 M
