Supermicro's X11 DP/UP SuperServer®, SuperWorkstation, SuperStorage, and SuperBlade®solutions offer numerous advantages over previous generations and the highest levels of performance, efficiency, security and scalability in the industry. Supermicro X11 SuperServers support the latest Intel® Xeon® Scalable processors and offer 3TB ECC 3DS LRDIMM or RDIMM DDR4-2666MHz memory in 24 DIMMs, 7 PCI-E slots, SAS 3.0/SATA 3.0/NVMe hot-swap HDD/SSD support, 10GBase-T/10G SFP+/56Gbps FDR InfiniBand networking options, redundant Titanium Level (96%+) Digital power supplies, and IPMI 2.0 plus KVM with dedicated LAN. The SuperWorkstation systems offer in addition 7.1 HD Audio, SLI and Thunderbolt support, and up to 11 USB ports.
-
SKU:
- 1040987360
Manufacturer:
Supermicro Computer, Inc
Manufacturer Part Number:
SYS-7049P-TR
Manufacturer Website Address:
http://www.supermicro.com
Brand Name:
Supermicro
Product Line:
SuperServer
Product Model:
7049P-TR
Product Name:
SuperServer 7049P-TR (Black)
Product Type:
Barebone System
Number of Processors Supported:
2
Processor Socket:
Socket P LGA-3647
Processor Supported:
Xeon Platinum,Xeon Gold,Xeon Silver,Xeon Bronze
64-bit Processing:
Yes
Chipset Manufacturer:
Intel
Chipset Model:
C621
Maximum Memory Supported:
2 TB
Memory Technology:
DDR4 SDRAM
Memory Standard:
DDR4-2666/PC4-21300
Number of Total Memory Slots:
16
Controller Type:
Serial ATA/600
RAID Supported:
Yes
Graphics Controller Manufacturer:
ASPEED
Graphics Controller Model:
AST2500
Ethernet Technology:
Gigabit Ethernet
Number of Total Expansion Bays:
11
Number of External 5.25" Bays:
3
Number of 3.5" Bays:
8
Number of Total Expansion Slots:
6
Number of PCI Express x8 Slots:
2
Number of PCI Express x16 Slots:
4
Total Number of USB Ports:
7
Number of USB 3.0 Ports:
2
Number of SATA Interfaces:
8
Input Voltage:
120 V AC,230 V AC
Number of Power Supplies Installed:
2
Maximum Power Supply Wattage:
1280 W
Product Color:
Black
Form Factor:
Tower
Rack Height:
4U
Height:
17.8"
Width:
7"
Depth:
25.5"
Weight (Approximate):
56 lb
Package Contents:
- SuperServer 7049P-TR (Black)
- 1 x Super X11DPi-N Motherboard
- 1 x 4U Chassis
- 1 x 8-port 4U/Tower 3.5-inch SAS3/SAS2/SATA3 12Gbps backplane for SC743/SC745 chassis
- 2 x MINI SAS HD-MINI SAS,6G,INT,50CM,SB,30AW
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Limited Warranty:
3 Year
sku variation:
The Supermicro SYS-7049P-TR is also known as SUP-SYS7049PTR or SYS7049PTR
Brand Logo:
https://content.etilize.com/Brand-Logo/1040987360.jpg
Short Description:
Super Micro, X11DPI-N-P, CSE-745BTS-R1K28BP2, 4U Tower Mainstream Server, Ncnr Required
Accessories:
1041183314,1041429549,1025440907,1022258821,1019681929,1011321793
