Following in the footsteps of the industry recognised SRP-E770 series, the entry-level XD3-40d is a new Direct Thermal 4-inch (118mm) Desktop workhorse offering day-to-day quality 203 dpi output across your logistics, warehousing and manufacturing installations. Simple to setup and use, the XD3-40d also benefits from tool-less printhead and platen replacement to ensure uptime is maximised. Product or asset labelling, Document management, patient and quest identification, Shipping and logistics printing, the XD3-series offers a balance of cost and performance, including print speed, tear and peel media handling, plus networked options.
-
SKU:
- 1072394206
Manufacturer:
Bixolon America, Inc
Manufacturer Part Number:
XD3-40DDK
Manufacturer Website Address:
http://www.bixolon.com
Brand Name:
Bixolon
Product Series:
XD3-40
Product Model:
XD3-40d
Product Name:
4 inch Direct Thermal Label Printer
Product Type:
Direct Thermal Printer
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
5 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Length:
39.37"
Maximum Print Width:
4.09"
Barcode Symbology Supported:
Codabar,Code 11,Code 39,Code 93,Code 128,EAN-13,EAN-8,Industrial 2 of 5,Interleaved 2 of 5,LOGMARS,MSI,Plessey,POSTNET,GS1 DataBar,Standard 2 of 5,UPC/EAN,UPC-A,UPC-E,IMB,Aztec Code,Codablock,Code 49,Data Matrix,Maxi Code,Micro PDF-417,PDF417,QR Code
Fonts Included:
10 SLCS,One SLCS,16 BPL-Z,One BPL-Z,5 BPL-E,23 Code Page,Unicode supported,UTF-8,UTF-16LE,UTF-16BE
Peel Facility:
Yes
Application/Usage:
Desktop
Standard Memory:
64 MB
USB Host:
Yes
USB:
Yes
Media Type:
Label,Gap,Black Mark,Notch,Fanfold,Continuous Label
Media Sensor:
Transmissive Media Sensor,Reflective Media Sensor,Head Open Sensor
Media Thickness:
7.87 mil
Maximum Roll Diameter:
5"
Maximum Label Width:
4.65"
Language Emulation:
SLCS,BPL-Z,BPL-D,BPL-E
Operating System Supported:
Driver / Utility Windows Driver (Europlus / Seagull) Linux / Mac CUPS Driver Virtual COM USB / Ethernet Driver, Utility Program, OPOS Driver Bartender Ultralite for BIXOLON Label Artist-II&trade SDK / Plugin Windows SDK, Linux SDK
Power Source:
Power Adapter,AC Supply
Input Voltage:
120 V AC,230 V AC
Operating Temperature:
32°F (0°C) - 104°F (40°C)
Operating Relative Humidity:
10% - 80%
Storage Temperature:
-4°F (-20°C) - 140°F (60°C)
Storage Relative Humidity:
10% - 90%
Product Color:
Black,Orange
Height:
6.6"
Width:
7.1"
Depth:
8.7"
Weight (Approximate):
3.75 lb
Power Cable Localization:
US
Optional Connectivity:
Ethernet,Serial (RS-232)
Platform Supported:
PC,Mac
Energy Star:
Yes
sku variation:
The Bixolon XD3-40DDK is also known as BIX-XD340DDK or XD340DDK
Brand Logo:
https://content.etilize.com/Brand-Logo/1072394206.jpg
Short Description:
Bixolon, XD3-40DK, Black, Usb, Peeler, 5IPS, 127MM SEC Print Speed, Direct Thermal, 203 Dpi, 15 118MM Label Media Width, UP To 127 MM Roll D. Power Supply US Power Cord, Label Artist Design Prog WTY L
