Zebra incorporated extensive customer feedback, as well as the legacy of our industry leading Stripe and S4M printers, to create the new ZT200 Series family of printers with elegant space saving design, effortless setup, intuitive user operation, and ease of service and maintenance.
-
SKU:
- 1024252772
Manufacturer:
Zebra Technologies Corporation
Manufacturer Part Number:
ZT23043-T21100FZ
Manufacturer Website Address:
http://www.zebra.com
Brand Name:
Zebra
Product Series:
ZT200
Product Model:
ZT230
Product Name:
ZT230 Industrial Printer
Product Type:
Direct Thermal/Thermal Transfer Printer
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
6 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Width:
4.09"
Barcode Symbology Supported:
Code 11,Code 39,Code 93,Code 128-A,Code 128-B,Code 128-C,UCC Case Codes,ISBT-128,UPC-A,UPC-E,EAN-13,EAN-8,EAN With 2 or 5 Digit Extension,UPC 2 or 5 Digit Extension,Plessey,POSTNET,Standard 2 of 5,Industrial 2 of 5,Interleaved 2 of 5,LOGMARS,MSI,RSS
Application/Usage:
Industrial
Features:
Clear Bi-fold Media Side Door,Element Energy Equalizer,Bi-color LED,Icon-graphics,Tear Bar
Standard Memory:
128 MB
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Display Screen:
Yes
Display Screen Type:
LCD
Cutter:
Yes
Media Type:
Continuous Label,Die-cut Label,Notch,Black Mark
Media Sensor:
Transmissive Media Sensor,Reflective Media Sensor
Media Thickness:
10 mil
Maximum Roll Diameter:
8"
Maximum Label Width:
4.50"
Maximum Label Length:
39"
Language Emulation:
ZPL
Power Source:
AC Supply
Input Voltage:
110 V AC,220 V AC
Height:
10.9"
Width:
9.5"
Depth:
17"
Weight (Approximate):
20 lb
Package Contents:
- ZT230 Industrial Printer
- Power Cord with US Plug
Platform Supported:
PC
Certifications & Standards:
- IEC 60950
- EN 55022 Class B
- EN55024
- EN 61000-3-2
- EN 61000-3-3
- UL
- CE Marking
- FCC-B
- ICES-003
- VCCI
- C-Tick
- NOM
- IRAM
- CCC
- GOST-R
Energy Star:
Yes
Environmentally Friendly:
Yes
sku variation:
The Zebra ZT23043-T21100FZ is also known as ZEB-ZT23043T21100FZ or ZT23043T21100FZ
Brand Logo:
https://content.etilize.com/Brand-Logo/1024252772.jpg
Short Description:
Zebra Ait, Disco, Refer To ZT41143-T210000Z + P1058930-075, ZT230, 4IN, 300DPI, Thermal Transfer, Cutter With Catch Tray, Power Cord With US Plug, Serial,usb,parallel, ZPL
